Mitutoyo U-WAVE fit Buzzer Type Wireless Transmitter for Caliper 264-621

• Approx. 20 m (within visible range).
• Communication frequency: 2,4GHZ wireless system for reliable and secure data transmission.
• Easy data export to Easy data export to Microsoft® Excel® or other professional SPC software applications like Mitutoyo MeasurLink.
• Transmitter confirms data transfer by a buzzer sound or a red/green LED signal.
• An IP67 transmitter is available.
• Low power consumption: 400.000 data transmissions with one battery.
• U-WAVE Event will also support a data request from a PC. This is ideal if the system is installed at an inaccessible side.

Mitutoyo 264-621 U-Wave Fit Buzzer Transmitter for Calipers Mitutoyo’s new U-Wave Fit wireless data transmitter fits to the back of popular Mitutoyo hand-held measuring instruments. This new design allows for a snug fit behind the display resulting in a more ergonomic feel. U-Wave Fit is the same technology as the U-Wave T, just a smaller version.• The transmitter is designed to fit in the space behind the display, and the connecting cable hasbeen replaced by a rigid connector• Approx. 20 m transmission range (within visible range)• 2.4GHz wireless system for reliable and secure data transmission• Easy data export to Microsoft® Excel® or SPC software applications• Transmitter confirms data transfer by an LED signal and optional buzzer• An IP67 transmitter is available to ensure a coolant-proof gaging system• Low power consumption: 400.000 data transmissions with a single battery

Key Specifications

Measuring Instruments: 100, 150, 200, 300 mm IP67 caliper/standard caliper

Remarks: Standard

Data reception indication: Buzzer and LED (green, red, orange)

Transmission output: 2,5 mW (4 dBm) or below

Mass_ 20 g

Wireless communication protocol: Proprietary (2.4 GHz by original specification based on IEEE 802.15.4)

Power supply: Battery CR2032 x 1 pcs.

Communication distance: Approx. 20 m (within visible range)

Communication speed kbps: 250

Communication frequency: 2,4 GHz band (2,405-2,475 GHz, 15 channels, 5 MHz interval)

Communication with measuring tool: Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification

OS compatibility: Windows® 2000 Professional (≥SP4), Windows® XP Professional (≥SP2), Windows® XP Home Edition (≥SP2), Windows Vista®, Windows® 7 (32bit, 64bit), Windows® 8, 8. 1, 10 (32bit, 64bit)

Battery life: Approx. 400000 transmissions

Dimensions (WxDxH): 56 x 30.4 x 11.5 mm

Functions: Measurement data transmission (cancel command, error command) and U-WAVE-R scan

Brand Information

Mitutoyo History - Celebrating over 80 years in the Metrology industry! Mitutoyo started from humble beginnings in 1934 in Japan and are now recognised as a world leading manufacturer of measuring tools such as micrometers, calipers, and system instrument products such as co-ordinate measuring instruments, form measurement instruments and optical measuring instruments
